Diamond Systems Corporation, based in Sunnyvale, California, has been providing rugged, I/O-rich embedded computing solutions since 1989. The company offers a wide range of products, including single-board computers (SBCs), I/O expansion modules, Ethernet switches, and power supply solutions, all designed to operate in harsh environments.
Their products are utilized across various sectors such as transportation, energy, aerospace, defense, manufacturing, medical, and research. Diamond Systems is renowned for its innovative use of standards like PC/104 and COM Express, as well as for delivering customized solutions tailored to specific customer requirements.
Their products are engineered to withstand extreme temperatures, vibrations, and other challenging conditions, making them suitable for applications in military vehicles and industrial automation.
Read more: Diamond Systems
The Aries PC/104-Plus single board computer from Diamond Systems uses the Intel “Bay Trail” E3800 series processor to deliver an unmatched combination of performance, price and power consumption.
Athena IV is the fourth generation in the Athena family of rugged, wide-temperature PC/104 SBCs with Integrated data acquisition, extending back to the original Athena in 2004.
Two optional analog outputs provide 12-bit resolution over a 0-5V or user-adjustable range with 8mA drive current and 4μs settling time.
PCIe MiniCard I/O Expansion Module with Dual CANbus Ports
The DS-MPE-DAQ0804 is a rugged, low cost data acquisition PCIe MiniCard module with both analog and configurable digital I/O.
PCIe MiniCard Gigabit Ethernet Module
The DS-MPE-GPIO is a rugged, low cost 36-channel digital I/O PCIe MiniCard module that is ideal for digital I/O expansion in embedded and OEM applications.
The DS-MPE-SER4M is a rugged, low cost 4-port high speed PCIe MiniCard module that is ideal for serial I/O expansion in embedded and OEM applications.
The DS-MPE-SER4OPT is a rugged, low cost 4-port opto-isolated PCIe MiniCard serial module that is ideal for serial I/O expansion in embedded and OEM applications where opto-isolation is needed for safety or for ground loop prevention.
Rugged Carrier for NVIDIA® Jetson™ AGX Xavier™ Module
Our Emerald-MM PC/104 module gives you 4 serial ports operating at speeds up to 115kbps. In RS-232 mode, the full complement of standard PC serial port signals (8 signals + ground) are provided for each port and are grouped onto two 20-pin headers (2 ports per header)
The Emerald-MM-8EL-XT is a family of high performance PCIe/104 "OneBank" serial I/O modules offering 4 or 8 multiprotocol serial ports with software-controlled configuration and optional opto-isolation.
Emerald-MM-8P offers 8 multi-protocol serial ports on a single PC/104 module with complete software configurability via the operating system
EMERALD-MM-8PL-XT PC/104 Octal Serial Port Module
Emerald-MM-8Plus is a high performance multi-protocol serial communications board offering eight ports on a single PC/104-Plus module.
Emerald-MM-Opto provides an integrated, rugged, and reliable solution for PC/104-expandable embedded systems requiring serial communications in demanding applications.
DIAMOND SYSTEMS EPS-12000-CM MINI MANAGED L2/L3 ETHERNET SWITCH. COMPACT EXT-TEMP MANAGED 12-PORT L2/L3 GBE SWITCH.
EPS-8130 Managed 8-Port Gigabit Ethernet switch with embedded layer 2 software
MANAGED 28-PORT GBE SWITCH, 4 10G SFP, WIDE VOLTAGE INPUT AND SERIAL MANAGEMENT PORT
Managed 14-Port Gigabit Ethernet Switch. Standalone COM Express module with wide voltage input and serial management port
